The SlimTwin is the world’s slimmest dual gyro survey instrument.

The SlimTwin is the world’s slimmest dual gyro survey instrument. Fully integrated with a diameter of only 25 mm it offers a truly unique two-gyros-in-one ultra-slim package. No special pre- or post-survey procedures are necessary to get into the hole. The simple set-up saves valuable site-time and potential sources of human error are significantly reduced. Application Guide: Blasting / Production, RC Drilling, Coring and Diamond Drilling

⚙️ Slimmest & lightest on the market ⚙️ High rate - low power

⚙️ High-end calibration ⚙️ From vertical to any orientation

Centralized config

Diameter: 25 mm

Length: 2360 mm

Weight: 5.20 kg

Bullnose config

Diameter: 25 mm

Length: 1390 mm

Weight: 2.50 kg

Accuracy

Inclination: ± 0.10°

Azimuth: ± 0.50°

Gravity high side: ± 0.15°

Gyro toolface: ± 0.50°

Position accuracy: < 0.2% (2m/1000m)*

Rate range: ± 1000 °/s

Performance

Temperature Range: -20°C to +80°C

Modes of operation: Memory, All inclinations, Continuous, MultiShot, Orientation

Battery time: 50 hours

Battery type: Rechargeable NiMH

Communication: Bluetooth

Power consumption: 0.4 W

Control

Software: Surveyor, Windows 10 & 11

Data management: SurveySafe cloud portal system

Recommended: Getac UX10, rugged tablet PC (MIL-STD-810G)

* Depending on borehole profile and survey procedure
