Its simple set-up saves valuable site-time and reduces potential sources of human error.

The fully integrated TwinGyro offers our unique two-gyros-in-one technology in a rugged 35 mm package. It is ideal for surveying where hole diameter is not an issue and getting two surveys per run significantly cuts rig downtime. Its simple set-up saves valuable site-time and reduces potential sources of human error. Application Guide: Directional drilling, Coring / Diamond Drilling and Raise Bore

⚙️ Dual gyro technology ⚙️ High rate - low power

⚙️ High-end calibration ⚙️ Independent backup

⚙️ From vertical to any orientation

Standard config

Diameter: 35 mm

Length: 1605 mm

Weight: 7.65 kg

In-rod spacers config

Diameter: 35 mm

Length: 1857 mm

Weight: 9.45 kg

Stinger orientation config

Diameter: 35 mm

Length: 2090 mm

Weight: 10.15 kg

Core retriever config

Diameter: 35 mm

Length: 1980 mm

Weight: 10.80 kg

Centralized config

Diameter: 35 mm

Length: 2570 mm

Weight: 12.60 kg

Accuracy

Inclination: ± 0.10°

Azimuth: ± 0.50°

Gravity high side: ± 0.15°

Gyro toolface: ± 0.50°

Position accuracy: < 0.2% (2m/1000m)*

Rate range: ± 1000 °/s

Performance

Temperature Range: -20°C to +80°C

Modes of operation: Memory, All inclinations, Continuous, MultiShot, Orientation

Battery time: 100 hours

Battery type: Rechargeable NiMH

Communication: Bluetooth

Power consumption: 0.4 W

Control

Software: Surveyor, Windows 10 & 11

Data management: SurveySafe cloud portal system

Recommended: Getac UX10, rugged tablet PC (MIL-STD-810G)

* Depending on borehole profile and survey procedure
