RELIABLE PRECISION EVEN IN HARSH CONDITIONS

Gyro measurements built to withstand heat, vibration, and high-risk drilling, enabling faster, safer completion in the field.

Problem

Energy projects demand exact alignment and reliable measurements. Traditional survey tools often fail under harsh conditions, creating risk and uncertainty.

Solution

Our gyro survey systems deliver drift-free orientation and high-resolution data in any environment, giving engineers full operational control.

Result

Projects proceed with confidence, reducing rework, improving efficiency, and ensuring safety and compliance at every stage.

TALK WITH OUR BUSINESS MANAGER

APPLICATION AREAS

  • DROP GYRO

  • GEOTHERMAL

  • MICRO DOGLEG

  • WHIPSTOCK ORIENTATION

  • WIRELINE

TALES FROM THE FIELD

RECORD DEPTH & TIME OF SURVEY

“The SlimGyro set a record by successfully surveying depths over 6,000 meters in a continuous 31-hour operation. Its durability and low power consumption make it ideal for extreme conditions, enabling the mapping of geothermal reservoirs for sustainable energy development.”

SWEDISH NUCLEAR WASTE REPOSITORY

“The TwinGyro was selected by SKB for new drilling at Forsmark — Its dual-gyro system provides superior accuracy while reducing rig downtime, ensuring compliance with strict safety and geological stability.”

SKB logo with three vertical blue stripes and white block letters.

TwinGyro at OilWell Guidance

“The TwinGyro made our market entry possible.”

Kelsey Long, OilWell Guidance

RECOMMENDED PACKAGES

  • TwinGyro™ with 1.75” heatshield

    For all types of work in standard rods the TwinGyro™ with a 1.75” heatshield is ideal. Run on slickline, E-line or as a dropgyro at all depths. Ideal for dropgyro surveys, produce two independent surveys from the single chance pulling out of hole.

    Package includes:

    • Complete TwinGyro™ survey kit
    • Rugged field computer: Algiz 10X or Toughbook
    • 1.75” NKW heatshield:
    - Pressure: 22,000 PSI
    - Temperature: 12 h at 350 F (180 C)

    • Slickline, E-line and dropgyro accessories, including:
    - Blade centralizers
    - Finger guide subs
    - Orienting subs
    - PCC spear point and overshot
    - Landing plate
    - Wireline swivel
    - Optical and GPS alignment systems

  • SlimGyro™ with 1.2” heatshield

    For surveying in tight production holes without the need to pull the tubing the SlimGyro™ is ideal. The 1.2” heatshield can fit into tubing where no other gyro can go. It can also be used in standard slickline, E-line and dropgyro configurations.

    Package includes:

    • Complete SlimGyro™ survey kit
    • Rugged field computer: Algiz 10X or Toughbook
    • 1.2” NKW heatshield:
    - Pressure: 15,000 PSI
    - Temperature: 4 h at 350 F (180 C)

    • Slickline, E-line and dropgyro accessories, including:
    - Blade centralizers
    - Finger guide subs
    - Orienting subs
    - PCC spear point and overshot
    - Landing plate
    - Wireline swivel
    - Optical and GPS alignment systems

  • Continuous wireline micro-dogleg survey

    Micro-dogleg surveys require a dense array of stations and are only practical in continuous survey mode. Both the TwinGyro™ and SlimGyro™ are capable of such surveys when combined with an optical encoder package. The encoder can be purchased from us for mounting but it is often possible to interface directly to an existing wireline encoder on the survey truck or rig.

    Package includes:

    • Complete SlimGyro™ or TwinGyro™ survey kit
    • Rugged field computer: Algiz 10X or Toughbook
    • 1.2” or 1.75” NKW heatshield
    • Slickline and E-line and accessories, including:
    - Blade centralizers
    - Finger guide subs
    - Orienting subs
    - PCC spear point and overshot
    - Landing plate
    - Wireline swivel
    - Optical and GPS alignment systems
    - Optical depth encoder package

  • Custom configurations

    All packages can be customized to suit specific needs. Contact us or a distributor to discuss the possibilities.

REQUEST QUOTE

Stop guessing and save both effort and money with our quality technology and modern solutions. Connect with our business manager, who will tailor the best deal to your needs.

Let’s talk accuracy.
Connect with our business manager.

CONNECT HERE
